Teradek Wireless

Bolt 7 750 TX 2701

MFR# 10-2701

Prix en magasin: 3.040,57€ + TVA

Prix en ligne: 2.918,94€ + TVA

4K Wireless Video Transmitter
12G/SD-SDI & HDMI Connectors
Up to 4096x2160 50P/60P
V-Mount Plate

Pas en stock
Pre-Order only

The Bolt 4K 750 TX is a real time wireless video transmitter that supports 1080p and 2160p video signals at 60FPS with less than 1ms of delay up to 750 feet. Key features include increased range, faster reconnection times, easier setup with Bluetooth App for iOS or Android, and more stable connectivity. These devices are cross-compatible with the entire Bolt 4K Family. Includes integrated 1/4"x20 and M3 mounting points. Optional Battery Plates are sold separately.

Real-Time 4K Wireless Video
Transmit uncompressed video in 1080p and 2160p at 60FPS with less than 1ms of delay. Up to 750 feet of range.

True HDR Color
Bolt 4K is compliant with the HLG, PQ, and HDR-10 standards, making it an invaluable tool on set for HDR workflows.

Rock-Solid Reliability
Bolt 4K features 8x the wireless performance of previous Bolt generations, ensuring video is delivered in even the toughest of RF environments.

Universal Compatibility
Each transmitter can send video to up to 6 receivers. Compatible with any model in the Bolt 4K line.

Inputs/Outputs
1x 12G-SDI, 1x HDMI 2.0,
1x 12G-SDI loopout

Battery Plates
Optional Gold Mount or V-Mount battery plate with pass-through power available.

Camera Metadata
Send start / stop flags, timecode, and other ancillary data over the wireless link. On the receiver side, upload and apply custom 3D LUTs to monitor each take with the look you’re after.

Bolt App for iOS
Remotely pair units, configure settings, and utilize all of Bolt 4K’s features from any iOS smartphone or tablet. The Bolt App uses Bolt 4K’s integrated Bluetooth to give you all of its settings in the palm
of your hand.

Source: https://teradek.com/products/bolt-7-tx?variant=47768075075762

STATUS

Status: New
Availability: Pre-Order only
Type of Wireless: Wireless Video Transmitter

TRANSMITTER FEATURES

Video inputs (Transmitter): 12G/HD/SD-SDI (BNC)
HDMI 4K
No of Video inputs (Transmitter): 1/1
Video outputs (Transmitter): 12G/HD/SD-SDI (BNC)
No of Video outputs (Transmitter): 1
Audio inputs (Transmitter): 2CH embedded audio SDI
PC Connections (Transmitter): USB-C
Transmitter Mount: 1/4" holes
Dimensions(Transmitter): 112x66x32mm
Weight(Transmitter): 0.400KG
Power (Transmitter): 6-28V 2-pin lemo (20Watts)

WIRELESS FEATURES

Video Resolution: 24P/25P/30P/50P/60P @4096x2160Pixel
24P/25P/30P/50P/50i/60P/60i @1920x1080Pixel
50P/60P@1280x720Pixel
50i/50P @720x576Pixel
60i/60P i@720x480Pixel
Range: 230m line of sight
Wireless Frequency: Non-DFS Frequencies: 5.190 ~ 5.230 GHz, 5.755 ~ 5.795 GHz, 5.945 ~ 6.425GHz
DFS Frequencies: 5.270 ~ 5.670 GHz
RF Output Power (mW): 50.0
Delay (sec): 0.001

MORE SPECIFICATIONS

Extras: 4:2:2 10Bit Video Processing.
HDMI: RGB 4:4:4, 8/10bit.
USB-C for Firmware updates.
OLED Screen.
Mount: 1/4" holes
Power: Power adapter
Power Consumption: 20 Watt
Country of Origin: USA
Warranty: 1 Year
