Metabones

Adapter EF to E-Mount CINE ND

MFR #MB_NDEF-E-BM7
Price: € 660.06 + VAT
Online price: € 633.66 + VAT
✓ Installment payments by credit card.
⌦ Not in stock. Available in 15working days.

  • Electronic?Lens Adapter Cine
  • For E-mount Sony Cameras
  • For Canon EF Lenses
  • ND and CLEAR swap system
  • Autofocus
  • Image Stabilization
  • High Quality
  • 1-year Warranty

Share this product

EF to E-Mount CINE ND

Description

Fast, Convenience, and Quality!

The Metabones EF to E mount CINE eND Smart Adapter is built-in with the swapping eND filter system, allowing users to change between the clear-glass filter and the eND filter in one click within a second. The internal system prevents the adapter and camera from the dust. The Smart Adapter provides an electronically variable ND. The eND module has a minimum setting of 2 stops and can provide up to 7 stops of exposure adjustment in 1/3 of a stop increments without degrading your image. It provides you with exposure control without requiring you to add ND glass to the front of the lens.

As always, Metabones is also the most feature-laden on the market. In addition to usual flair like support for autofocus and auto exposure, there are numerous features particularly pertinent to videography: cinema lens support, and smooth iris. Both in-body and optical image stabilization (IBIS, IS, OS and VC) are supported, with the necessary metadata and communication carefully crafted to maximize effectiveness no matter which camera or lens is used.

Features and Benifits

Exclusive

  • Built-in internal electronic ND filter and CLEAR filter swapping system
  • Electronically Variable ND filter with 2 to 7 Stops (ND4 to ND128)
  • ND 2 to 7 Stops of ND 1/3 of a Stop Increment
  • Powered by camera body. No external power source required.

Electronic

  • Autofocus
  • Fast contrast-detection AF on all E-mount cameras with most lenses.
  • Pure phase-detection autofocus support on A9, A7RIII, A7III, A7RII, A7II, A6500 and A6300.
  • AF-C tracking during high-speed drive at up to 10fps on Sony A9, A7III and A7RIV.
  • Store EXIF data (lens name, focal length and maximum/minimum aperture) for up to 2 manual lenses in the adapter.
  • If both your lens supports optical image stabilization (OIS) and your camera supports sensor-shift, in-body image stabilization (IBIS), the choice is yours on which one to use, or have both of them work in harmony.
  • Smooth iris support with the latest Canon (2009+), Tamron (SP series 2013+) and Sigma (2016+) lenses.
  • Custom function button (called Focus Hold button) assignable to more than 50 functions, such as Aperture Preview and Eye-AF, on A9, A7 series, A6500 and A6300.
  • Dedicated switch controls in-body image stabilization (IBIS) on Sony cameras equipped with SteadyShot INSIDE.
  • Sony E-mount teleconverter support.
  • Cinema EOS lens (CN-E Compact-Servo) support, including power zoom, AF and auto iris.
  • Supports 5-axis in-body image stabilization of A7III, A7RIII, A7II, A7RII and A7SII. (Distance information from lens required; 3-axis IBIS if the lens does not transmit distance information.)
  • OLED panel displays operation mode, clear filter and ND filter status.
  • Efficient switched-mode power supply. Supports image stabilization (IS) lenses. Supports electronic manual focusing (e.g. EF 85/1.2L II and discontinued EF 50/1.0L)
  • EXIF support (focal length, aperture, lens name)
  • Distance and zoom display on VG and FS series camcorders, A9, A7 series, A6500 and A6300 (lens with distance information support required).
  • Auto magnify (lens with distance information support required)
  • Auto APS-C Size Capture on full-frame cameras with Canon EF-S lenses and many third-party DX lenses.
  • Autofocus.  AF speed is properly adjusted to account for and leverage the shorter focal length and the brighter maximum aperture.
  • Image stabilization (IS) lens support.
  • Build-in multi-function Control Wheel (turn/ push-in) for assignable functions(eg. ISO, shutter speed or aperture control, depth-of-field preview).
  • OLED display shows communication status.

Mechanical

  • Patented positive-lock EF lens mount.
  • Fits both EF and EF-S lenses. (Vignetting at corners may occur with certain EF-S lenses because they are designed to cover a 1.6x crop image circle but Sony APS-C has a 1.5x crop factor.)
  • Rubber gasket protects the E-mount connection from dust and moisture.
  • Aluminum alloy and brass construction with chromium plating.
  • Satin surface finish.





Limitations

Autofocus

  • AF-C is supported on A1, A9II, A9, A7SIII, A7RIV, A7IV, A7III, A7RIII, A7RII, A7II, A6700, A6600, A6500, A6400, A6300 and A6100 only.
  • Continuous video AF is functional in Advanced mode only, but performance may be unsatisfactory.
  • On Sony A9, only phase-detection autofocus is supported. Contrast-detection autofocus may not work satisfactorily.
  • AF may not work if the maximum aperture of the lens plus any EF Extender or other teleconverter attached is smaller than f/8.
  • The first few autofocus attempts are used to calibrate the lens and as a result may not lock successfully on the target. Half-press the shutter release button again and autofocus will lock successfully.
  • Autofocus may have difficulty locking onto subjects which are very close to the nearest focusing distance of the lens.
  • Autofocus accuracy depends heavily on the design and working condition of the lens. Lenses with hidden problems which may not be apparent on Canon DSLRs will lead to inaccurate and unreliable autofocus on Sony. Typical problems of this kind that we have seen include an unsmooth/erratic autofocus mechanism (e.g. getting stuck intermittently at a certain focusing distance), a faulty/worn-out distance encoder or other faulty/worn-out internal sensors.

Other

  • No support for lens corrections such as peripheral shading, CA and distortion.
  • Use of Canon Compact-Servo Cinema lenses such as CN-E 18-80mm T4.4 for still photography is not supported. (Functional, but slower than lenses designed for still photography.)
  • Some EF-mount lenses may make audible noises during iris changes and autofocus, which may be picked up by the built-in microphone of the camera during video recording. Use of an external microphone is advised. Some of the recently-introduced Canon-brand lenses are very quiet, however.
  • Early Tamron VC lenses such as the AF 28-300/3.5-6.3 XR Di VC LD Aspherical [IF] Macro (model A20), AF 18-270/3.5-6.3 Di II VC LD Aspherical [IF] MACRO (model B003), SP AF 17-50mm F/2.8 XR Di II VC LD Aspherical [IF] (model B005) may not be able to freely switch between OIS and IBIS because they may not report IS activity status. Later Tamron VC lenses equipped with USD or PZD focus motors are fine.
  • Some aftermarket battery grips may cause the aperture to change erroneously. This is a bug in the aftermarket battery grip but NOT arising from the Metabones Smart Adapter. Turn off the aftermarket battery grip or use a genuine Sony battery grip.



Tested Camera Bodies:

  • Sony alpha 1 (A1), A9 II, A9, A7CII, A7CR, A7RV, A7R IV, A7R III, A7R II, A7R, A7S III, A7S II, A7c, A7S, A7IV, A7III, A7II, A7
  • A6700, A6600, A6500, A6400, A6300, A6000, A5000
  • ILME-FX3, FX30 *
  • PXW-FX9, FX6 *
  • PXW-FS5M2, PXW-FS7M2, PXW-FS5, PXW-FS7, NEX-FS700, NEX-FS100 *
  • VENICE *
  • NEX-7, NEX-6, NEX-5R, NEX-5N, NEX-5, NEX-C3, NEX-3

* for using the VENICE, FX and FS series cameras, please switch the adapter to Advance Mode.

Incompatible cameras (does not fit):

  • NEX-EA50, NEX-VG900, NEX-VG30, NEX-VG20, NEX-VG10

Lens Compatibility Chart

Fast AF on all E-mount cameras. Max 10fps AF-C with A9 (Green Mode) and A7III /A7R IV (Advanced Mode) Phase-detect AF on A9II, A9, A7IV, A7III, A7RII to A7RIV, A7II, A6500, A6400, A6300 and A6100 only. On other cameras, may not be able to contrast-detect AF accurately if at all. Max 3fps with A7III.

Canon EF8-15mm f/4L USM Fisheye*
Canon EF-S10-18mm f/4.5-5.6 IS STM*
Canon EF17-35mm f/2.8L USM
Canon EF-S17-55mm f/2.8 IS USM
Canon EF-S18-55/3.5-5.6 IS II*
Canon EF-S18-135mm f/3.5-5.6 IS Nano USM*
Canon EF-S18-135mm f/3.5-5.6 IS STM*
Canon EF24-70mm f/2.8L II USM*
Canon EF24-105mm f/4L IS USM (Mark I)
Canon EF28-80mm f/3.5-5.6 III USM
Canon EF28-80mm f/3.5-5.6 II
Canon EF40mm f/2.8 STM*
Canon EF50mm f/1.2L USM
Canon EF50mm f/1.4 USM (1993)
Canon EF50mm f/1.8 STM*
Canon EF70-200mm f/2.8L IS II USM*
Canon EF70-200mm f/4L IS II USM*
Canon EF70-200mm f/4L USM (not IS)
Canon EF70-300mm f/4-5.6L IS USM*
Canon EF85mm f/1.2L II USM
Canon EF100mm f/2.8L IS USM Macro*
Canon EF100mm f/2.8 USM Macro (2000)
Canon EF100-400mm f/4.5-5.6L IS II USM*
Canon EF135mm f/2L USM
Canon EF200mm f/2.8L II USM
Canon EF300mm f/2.8L IS II USM*
Canon EF300mm f/4L IS USM
Canon EF400mm f/5.6L USM
Canon EF Extender 1.4x (all versions)
Canon EF Extender 2x (all versions)
Kenko Teleplus Pro 300 1.4x (note 1)
Kenko Teleplus Pro 300 2x (note 1)
Sigma 18-35mm f/1.8 DC HSM Art 013
Sigma 18-125mm f/3.8-5.6 DC OS HSM
Sigma 24-105mm f/4 DG OS HSM Art 013
Sigma 30mm f/1.4 DC HSM Art 013
Sigma 50-100mm f/1.8 DC HSM Art 016*
Sigma 50-500mm f/4.5-6.3 DG OS HSM
Sigma 135mm f/1.8 DG HSM Art 017
Tamron 10-24mm f/3.5-4.5 VC HLD B023*
Tamron 15-30mm f/2.8 VC USD A012 (G1)
Tamron 18-270mm f/3.5-6.3 Di II VC PZD B008
Tamron SP 24-70mm f/2.8 VC USD A007 (G1)
Tamron SP 45mm f/1.8 VC USD F013*
Tamron SP 70-300mm f/4-5.6 VC USD A005
Tokina 11-16mm f/2.8 DX ATX Pro

Canon EF24-70mm f/2.8L USM (Mark I)
Canon EF28-70mm f/3.5-4.5 II (1988)
Canon EF28-135mm f/3.5-5.6 IS USM
Canon EF35mm f/1.4L USM (Mark I)
Canon EF50mm f/1.8 II (1990)
Canon EF100mm f/2 USM
Canon EF100-400mm f/4.5-5.6L IS USM (Mark I)
Contax N Vario Sonnar 17-35mm f/2.8
Contax N Planar 50mm f/1.4
Contax N Vario Sonnar 70-200mm f/3.5-4.5
Contax N Planar 85mm f/1.4
Sigma 50mm f/1.4 DG HSM (not Art)
Tamron 17-50mm f/2.8 Di II VC B005
Tamron 18-270mm f/3.5-6.3 Di II VC LD Aspherical [IF] MACRO B003
Tamron 18-250mm f/3.5-6.3 XR Di II LD Aspherical [IF] MACRO A18
Tamron 28-300mm f/3.5-6.3 XR Di VC LD Aspherical [IF] MACRO A20
Tamron 28-300mm f/3.5-6.3 XR Di LD Aspherical [IF] MACRO A06
Tamron SP 150-600mm f/5-6.3 VC USD A011 (G1)*
Phase-detect AF on A9, A7RIV, A7III, A7RIII, A7RII, A7II, A6500, A6400 and A6300. Not known if other cameras autofocus satisfactorily using contrast-detection, and it is not known if the maximum AF-C drive speed of 10fps with A7III & A7RIV can be achieved or not. Manual focus only

Canon CN-E 18-80mm T4.4 COMPACT-SERVO EF (note 2)
Canon CN-E 70-200mm T4.4 COMPACT-SERVO EF (note 2)
Canon EF 11-24mm f/4L USM
Canon EF 14mm f/2.8L II USM
Canon EF 16-35mm f/2.8L USM
Canon EF 16-35mm f/4L IS USM
Canon EF 20-35mm f/3.5-4.5 USM
Canon EF 24mm f/1.4L USM
Canon EF 24-70mm f/4L IS USM
Canon EF 24-105mm f/4L IS II USM
Canon EF 28-300mm f/3.5-5.6L USM
Canon EF 35mm f/1.4L II USM
Canon EF 35mm f/2L IS USM
Canon EF 35-350mm f/3.5-5.6L USM
Canon EF 70-200mm f/2.8L IS USM (Mark I)
Canon EF 70-200mm f/2.8L USM (non-IS)
Canon EF 70-200mm f/4L IS USM (Mark I)
Canon EF 75-300mm f/4-5.6 IS USM
Canon EF 85mm f/1.8 USM
Canon EF 180mm f/3.5L Macro USM
Canon EF 400mm f/2.8L IS USM (Mark I)
Canon EF 500mm f/4L IS USM (Mark I)
Sigma 12-24mm f/4.5-5.6 (Ver I)
Sigma 20mm f/1.4 DG HSM Art
Sigma 24mm f/1.4 DG HSM Art
Sigma 35mm f/1.4 DG HSM Art
Sigma 50mm f/1.4 Art
Sigma 70-200mm F2.8 APO EX DG OS HSM
Sigma 85mm f/1.4 EX DG HSM
Sigma 150mm f/2.8 Macro
Sigma 150-600mm f/5-6.3 OS HSM Contemporary
Tamron 16-300mm f/3.5-6.3
Tamron 18-200mm f/3.5-6.3
Tamron SP 70-200mm f/2.8 Di VC USD A009 (G1)*
Tamron 70-300mm f/4-5.6 (not VC)
Tamron SP 90mm f/2.8 Macro
Tokina 10-17mm f/3.5-4.5 DX
Tokina 11-16mm f/2.8 DX II

Canon TS-E 17/4L
Canon TS-E 24/3.5L
Canon TS-E 90/2.8L Marco
Samyang 35/1.4
Sigma 18-35/T2.0
Zeiss CP.2 25mm/T2.9
Zeiss CP.2 100mm/T2.1
Zeiss ZE Distagon 15/2.8
Zeiss ZE Distagon 18/3.5
Zeiss ZE Distagon 21/2.8
Zeiss ZE Distagon 25/2.8
Zeiss ZE Distagon 35/2
Zeiss ZE Planar 50/1.4
Zeiss ZE Makro-Planar 50/2
Zeiss ZE Planar 85/1.4
Zeiss ZE Makro-Planar 100/2
Not supported

Focus confirmation "chip" (e.g. Dandelion)

* with smooth iris support

Lenses not listed above have not been tested but will most likely work on A9, A7RIV, A7III, A7RIII, A7RII, A7, A6600 A6500, A6400, A6300 and A6100 using phase detection autofocus. They may or may not autofocus satisfactorily on other cameras using contrast-detection autofocus. It is not known if the maximum AF-C drive speed of 10fps with A7III & A7RIV can be achieved or not.

Note 1: Note colour dot next to the words "Made in Japan" on the housing. Blue dot, which is the latest version, is preferred. May have compatibility issues when Kenko is used with certain lenses and/or stacked on top of another teleconverter. Stacking not supported except if both are the blue dot version.

Note 2: Use of Canon Compact-Servo Cinema lenses such as CN-E 18-80mm T4.4 for still photography is not supported. (Functional, but slower than lenses designed for still photography.)

Disclaimer: we are NOT licensed, approved or endorsed by Canon and Sony
