Recorder Ver.6 4ch-sku
Recorder Ver.6 4ch-sku
product-thumbnail
product-thumbnail

Magicsoft Software

Recorder Ver.6 4ch-sku

MFR# RECORDER-VER6-4CH
in-Store Price: 1.545,00€ + VAT
Online Price: 1.483,20€ + VAT
  • Ingest/Recording Software
  • 4 Channels (Optional Extra channels)
  • SD,HD,4K up to 3840x2160 25/50P
  • One Audio/Video Channel
Not in stock
Available on order: 15 Business Days
Add to Wishlist
MagicSoft Recorder is an ingest application designed for broadcast and post production markets.  It works for unattended 24 / 7 operation and scheduled capturing for usage scenarios like  multi-cam ingest and conformance recording.

The software works under Windows 10 / 11 and Server 2016 / 2019 / 2022 / 2025


The supported video modes are :
4K UHD 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
HD1080p 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
HD1080i 50 / 59.94
HD720p 50 / 59.94
SD PAL / NTSC

Supported inputs :
BlackMagic Design devices ( Decklink & Intensity ), AJA cards and NDI (YUV and RGBA)

Supported video modes :
SD, HD and 4K ( for all existing frame-rates )

Supported color spaces :
BT 601 (SD), BT 709 ( HD and 4K ), BT 2020 ( 4K )

Number of channels per PC :
maximum 8 channels

Number of independent recordings per channel :
maximum 2 recordings

Workflow video color depth :
10 bit 4:2:2 and 8 bit 4:2:2

Audio channels :
up to 16 channels ( 16 bit 48kHz )





Possibility to generate up-converted or down-converted recordings





Module for TimeCode and NLE support
Module for Web Browser Remote
Module for Transcode
Module for Closed Caption


The list of supported codecs and conteiners :
DV .avi .mov .mxf and rawDV
DVCPRO .avi and .mov
DNxHD 8 bit .mov and .mxf
DNxHD 10 bit .mov and .mxf
DNxHR .mov and .mxf
AVC Intra 50 / 100 .mxf



H264 using CPU    8 bit   .mp4 / .mov / .avi / .mkv and .ts



H264 using CPU  10 bit   .mp4 / .mov / .avi / .mkv and .ts
H264 8 bit using nVidia hardware acceleration   .mp4 / .mov / .avi / .mkv and .ts
H264 8 bit using Intel QSV hardware acceleration   .mp4 / .mov / .avi / .mkv and .ts
H264 8 bit using AMD hardware acceleration   .mp4 / .mov / .avi / .mkv and .ts
HEVC using CPU    8 bit .mp4 / .mov / .mkv and .ts
HEVC using CPU  10 bit   .mp4 / .mov / .mkv and .tsHEVC 8 bit using nVidia hardware acceleration .mp4 / .mov / .mkv and .ts
HEVC 10 bit using Intel QSV hardware acceleration  .mp4 / .mov / .mkv and .ts
Mpeg2  program stream / .ts
Mpeg4 .avi / .mkv
ProRes .mov
XDCAM 35 / 50  .mov and mxf
Uncompressed YUV 8 bit  .avi and.mov
Uncompressed YUV 10 bit .avi and.mov


Recommended formats*:

DnxHD 8 bit ( .mov & .mxf )
DnxHD 10 bit ( .mov & .mxf )
DnxHR ( .mov )
Prores ( .mov )
XdCam HD 50 ( .mxf )
*
Tested version : Avid Media Express 2018_12 using “Link to AMA” import method



Proxy & Convertions



Proxy resolutions can be generated for all video modes



Up-converted 1080i files can be generated for SD (either 4/3 or 16 /9)
1080i modes can produce down-converted PAL or NTSC
1080p (50 and 59.94) modes can produce down-converted 720p
4K UHD modes can produce down-converted 1080p
4K UHD ( 50 and 59.94) modes can produce down-converted 720p


Recommended hardware:



UHD 4K @ 59.94 or 8 channels HD



Intel server platform processor with 32-64 core RAM 48 / 64 GB (6 / 8 channels)
Intel socket 2066 processor with 16-32 core  RAM 32 GB (quad channel)
AMD server platform processor with 32-96 core RAM 64 GB (8 channels)

UHD 4K @ 59.94 or 8 channels HD (GPU encoding)
Intel socket 1700 / 1851   RAM 32 GB (dual  channel DDR5)
Intel / AMD socket  with nVidia RTX   RAM 32 GB (dual  channel DDR5)

Multichannel HD
Intel socket 2011 / newer  6 core CPU or better RAM 16 GB
AMD socket AM4 / AM5 6 core CPU or better RAM 16 GB

Multichannel SD
Intel socket 1151  Intel i3 or better  RAM 8 GB
AMD    Ryzen 3 or better RAM 8 GB

Minimum Requirements for HD 1080i capturing - 1 channel 1080 i HD
( XDCAM / AVC-intra 100 / ProRes / DnxHD / H264)
Intel socket 1155 processor i5 2500
Intel socket 1150 processor i5 4430
Intel socket 1151 processor i3 6100

Minimum Requirements for HD 1080i capturing  - 2 channels 1080 i HD
( XDCAM / AVC-intra 100 / ProRes / DnxHD / H264 )
Intel socket 1155 processor i7 2600
Intel socket 1151 processor i5 6500
Intel socket 1151v2  processor i3 8100
AMD socket AM4 processor Ryzen 3 1100
Source: https://magicsoft.tv/recorder.html

STATUS

Status
New
Availability
Available on order: 15 Business Days
Software Type
Ingest

GENERAL FEATURES

Max Resolution Supported
4K: 3840 x 2160pixels (16:9 aspect ratio)
Frames Supported
4K UHD 23.98/24/25/29.97/30/50/59.94/60
HD1080p 23.98/24/25/29.97 /30/50 /59.94/60
HD1080i 50 / 59.94
HD720p 50/59.94
SD PAL/NTSC
Formats Supported
H264, H265, ProRes, DNxHD, DNxHR, MPEG-2, DV, DVCPRO, DVCPRO HD
Recommended System Requirements
Intel i9 12-Core 32GB RAM
Hardware Support
AJA Video Boards/Boxes
Blackmagic Video Boards/Boxes
Operating System Supported
Windows 10
Windows 11

MORE SPECIFICATIONS

Extras
4 channels (Up to 8 optional video inputs).
TimeCode and NLE support.
Web Browser Remote.
Integrated scheduler.
Storage management.
Country of Origin
Europe
Warranty
1 Year

PHYSICAL

Total Dimensions (LxWxH)
10 x 10 x 4 cm
Total Weight
500 gr
