Datavideo Camera
PTC 280 w NDI Black
- Compact Pan/Tilt Camera (Black)
- With NDI HX
- 4K 3840x2160 50P/60P
- CMOS 1/2.5"8.51MP
PTC-280 Brand New 4K PTZ Camera
Datavideo is introducing the 4K50/60p PTZ camera lineup which includes the PTC-280 Professional PTZ Camera that can be easily controlled via traditional RS-422 serial port or IP remote control via DVIP (Datavideo proprietary protocol) or Sony VISCA over IP.
This brand new 4K camera series supports dual streaming output for A/V market applications, so you can easily stream to Facebook (RTMPS), YouTube simultaneously. It also works well with dvCloud.
Simultaneous Outputs
Connect your PTC-280 to multiple devices in your workflow for flexibility. All the outputs are active at the same time.
PTZ View Assist: Control up to four cameras
The camera control app is tailored for the Datavideo PTZ camera series. It can monitor the live streaming video from PTC-140, and PTC-280 series. The app can control up to 4 cameras simultaneously via DVIP, you can intuitively set up and recall the presets, and adjust white balance, focus and IRIS.
The app is able to decode the live streaming via RTSP, SRT, and NDI. Easily monitor the live streaming video and set up the parameters promptly in one application. Datavideo provides iOS and Android versions, which you can download on Google Play and App Store for free!
Adopts High-Quality and Reliable Sony CMOS Sensor
Datavideo PTZ cameras utilize high-quality Sony CMOS sensors to deliver exceptional image quality and reliability. Renowned for their performance in various lighting conditions, Sony CMOS sensors are widely used in broadcast, cinematic, and professional video cameras. Additionally, these sensors offer lower power consumption, which leads to reduced heat generation and a longer camera lifespan.
Broadcast Quality 4K Resolution
With built-in 1/2.5" CMOS sensor, supports resolution up to 2160p 50/60.
Low Noise in Low Light
Advanced 2D/3D noise reduction technology is also used to further reduce the noise while ensuring image sharpness.
Multiple Simultaneous Video Outputs
Supports simultaneous HDMI 2.0 and IP output up to 2160p 50/60 and also 3G-SDI output up to 1080p60/50.
Multiple Network Protocol with Dual Stream Function
Support RTSP and RTMPS protocols, easy to stream directly to two different CDN platforms and Datavideo dvCloud as well.
Compatible with Various Controller
Control real-time pan, tilt, and zoom camera movements with Datavideo PTZ View Assist APP, RMC-300A and RMC-180. With configurable preset positions supported.
Datavideo PTZ Cameras Support NDI Features
Datavideo's PTZ camera series now supports NDI (Network Device Interface) features, enhancing their versatility and integration capabilities. With NDI, these cameras can transmit high-quality, low-latency video over IP networks, making them ideal for live production environments. The implementation of NDI utilizes the DVIP (Datavideo Protocol) ports, ensuring seamless connectivity and control. This advancement allows users to leverage the flexibility of IP-based workflows, simplifying setup and reducing the need for additional cabling, ultimately streamlining the production process.
The Benefits of Using NDI PTZ Cameras
NDI Pan Tilt Zoom cameras offer several advantages for various applications, particularly in the realm of video production, broadcasting, live streaming, and video conferencing. NDI, or Network Device Interface, is a technology developed by NewTek that allows video and audio to be transmitted over a network, making it easier to integrate and manage multiple devices.
With NDI PTZ cameras, you can easily set up a multi-camera production environment, enabling you to capture different angles and perspectives for more dynamic and engaging content. Here are some reasons why using NDI PTZ cameras can be beneficial:
High-Quality Transmission
NDI PTZ cameras provide high-quality video and audio transmission over a network, enabling crisp and clear visuals for broadcasting, streaming, or video conferencing.
Integration & Scalability
NDI technology allows for easy setup and scalability, enabling you to add and manage multiple cameras seamlessly.
Reduced Cable Clutter
By utilizing a network for video and audio transmission, you reduce the need for multiple cables, simplifying the setup and reducing cable clutter in your workspace.
Remote Control
NDI PTZ cameras are designed for remote control of pan, tilt, and zoom functions, offering flexibility in camera positioning and framing without physical intervention.
Interoperability & Compatibility
NDI is a widely adopted standard in the industry, ensuring compatibility with various video production and streaming systems. This interoperability enhances flexibility and options for integrating the cameras into your existing workflow.
Cost-Effective
NDI PTZ cameras can be a cost-effective solution, especially when considering the reduced cabling and infrastructure requirements. They also offer a versatile alternative to stationary cameras.
One Ethernet Cable with NDI® | HX Technology
There is no need for multiple cables and complicated setup. Single-wire concept helps you to transfer video, audio, power, tally, and control over only one Ethernet cable.
Power Over Ethernet (PoE) functionality allows you transmit all the information and power over only one cable.
NDI® is a registered trademark of Newtek, Inc.
NDI® Virtual Input
PTC-280 as an video input source can be applied to various platforms: Skype, GoToMeeting, WebEx, Zoom, and more.
Power over Ethernet
The PTC-280 supports PoE for easy installation. No need to find local power outlets or hire an electrician to install outlets wherever you want to mount your camera. Simply run a single CAT 6 cable to power your PTC-280.
Tally Light
Green and red lights tally to show the preview and program status for broadcast applications.
Wide 71° Field of View
PTC-280 provides a wide Field of View of 71°, easily shooting all the scenes in the field.
Supports H.264/H.265 Video Compression
Support compression of resolution up to 3840x2160 with frame up to 59.94, 60fps and the second channel 1280x720p with 30fps compression. AAC, MP3 and PCM audio compression also supported.
Build a reliable SRT live streaming workflow with all Datavideo products
Datavideo's wide range of encoders, cameras, and hand-carry switchers are fully supported by SRT and dvCloud. Datavideo encoders and dvCloud provide reliable streams over unreliable networks.
By using a Datavideo encoder and dvCloud together, you can utilize SRT (instead of RTMP) on the initial problematic connection or "First Mile." After your video stream reaches dvCloud, you can depend on dvCloud's reliable, high-bandwidth network to deliver the stream to your favorite destinations, like Facebook and YouTube.
For more information on DVCloud, please visit the product page or sign up directly on www.dvcloud.tv
Remote control from anywhere in the world
Control the PTZ camera at the venue from anywhere in the world using the BB-1 KIT and dvCloud streaming service.
STATUS
- Status
- New
- Availability
- Available on order: 15 Business Days
- Camera Type
-
4K Camera
VIDEO SPECIFICATIONS
- Max Video Resolution
-
4K
- Slow Motion
-
No
- Rec Media
-
No media
LENS SYSTEM
- Sensor Type
-
CMOS
- Sensor Size
-
1/2.5" (crop factor 6.03)
- Sensor Resolution
-
8.51MP
- Lens Mount
-
Fixed
- Focal Length (35mm equivalent)
-
27mm to 318mm
- Optical Zoom
-
12X optical.
16x Digital.
- Max Aperture
-
Maximum: f/1.8 to 2.6
CONNECTIONS
- Video outputs
-
3G-SDI
HDMI
Ethernet (Video)
- Audio inputs
-
Jack 3.5mm
- Audio outputs
-
Embedded Audio SDI
Embedded Audio HDMI
Embedded Audio Ethernet
- PC Connections
-
USB
RS-422
Ethernet RJ-45
GENERAL FEATURES
- Pan/Tilt Operation
-
Yes
- Pan/Tilt Speed
-
Pan: 0.876°/s ~ 43°/s.
Tilt: 0.693°/s ~ 21.32°/s.
- Pan Range
-
300°
- Tilt Range
-
+130° to -15°
MORE SPECIFICATIONS
- Extras
-
H.264, H.265, MJPEG, Dual stream output.
Network Protocol: RTSP, RTMP, RTMPS,ONVIF,Multicast, NDI HX.
Black Color.
- Power
-
Power adapter
- Power Consumption
-
Not specified (12V)
- Country of Origin
-
China
- Warranty
- 1 Year
PHYSICAL
- Total Dimensions (LxWxH)
- 18.9 x 17.3 x 21.9 cm
- Total Weight
- 2.8 kg
- 1 x PTC-280 Camera
1 x IR remote controller
1 x Ceiling mount bracket -A
1 x Ceiling mount bracket -B
6 x Ceiling mount bracket screw M3*4mm
1 x DC 12V Power Adaptor
1 x Safety cable
-
